Electric Mortise Latch

ELECTRONIC SPECIFICATIONS

Voltage

24VDC or 12VDC

Solenoid wire size

24AWG

Reed switch wire size

22AWG

Other switch wire size

26-28AWG

MECHANICAL SPECIFICATIONS

Door Thickness

1-3/4”standard

Backset

2-3/4”

Trim

Outside lever is rigid when locked

Latch bolt

Stainless Steel, split, anti-friction, ¾” projection

Escutcheon

Brass or stainless steel

Lever Style

Sentinel (S)

Cylinder

6 pin Schlage® “C” Keyway, standard

CODE COMPLIANCE

UL

UL 10C Listed 3-hour rated

ANSI/BHMA

A156.13-2012 Grade 1 Certified

BAA

Meet the Buy American Act

ADA

All lever trims meet the American with Disabilities Act

RoHS

Meet requirement of EU RoHS Directive 2002/95EC

WARRANTY

1-year limited for electronic, 5-year limited for finish, 10-year limited for mechanical
